Advanced Electromechanical-Hydraulic Integration
APEX Industrial Hydraulic Double Roller Crusher: The Next-Gen Static Pressure Extrusion Platform
Static Pressure Extrusion Principle | Intelligent Hydraulic Protection | 20%-30% Energy Savings
Capacity: Up to 400 t/h | Max Feeding Size: ≤ 120 mm
The APEX Large Hydraulic Double Roller Crusher redefines large-scale mineral and aggregate reduction through continuous static pressure extrusion. Engineered for heavy-duty operational stability, this intelligent system continuously forces raw feeds through a strictly regulated gap controlled by counter-rotating twin rollers. By merging modern electromechanical-hydraulic automation, it serves as an ultra-reliable, high-profitability solution for hard rock metal mining, commercial sand processing, cement manufacturing, and industrial solid waste recycling.
APEX High-Performance Dual Alloy Roller Surface
Key Product Advantages
■ Intelligent Hydraulic Protection & Auto-Reset
Equipped with adaptive smart hydraulic control loops. If tramp iron or uncrushable mineral blocks pass the stream, the rollers instant-retreat via PLC tracking, bypassing dangers before auto-recalibrating to normal operating pressure lines within seconds. This ensures complete drive shaft safety.
■ Enhanced Crushing Efficiency & Eco-Isolation
Provides an instant 20% to 30% reduction in power consumption while increasing global tons-per-hour output by 30% to 40% over traditional kinetic impact crushers. The fully sealed structural body framework blocks site noise and guarantees total dust containment for strict environment rules.
■ Inter-Particle Grinding for Cubic Product Geometries
By breaking raw minerals directly along their natural grain boundaries via material bed compression, the system delivers high-yield premium cubic aggregate shapes. It slashes needle and flaky percentages to rock-bottom levels to meet premium concrete mix standards.
■ 3-5× Wear Resistance & Low Operational Overheads
The heavy-duty shell liners are cast from proprietary high-chromium manganese alloy matrices, expanding service life up to 500% over general steel parts. Backed by an intelligent control panel and a modular layout, on-site maintenance is simplified and fast.
Technical Parameters
| Model |
Roll Size (D×W mm) |
Max. Feed (mm) |
Capacity (t/h) |
Power (kw) |
| 2PGY1000×1000 |
φ1000 × 1000 |
≤ 60 |
80 – 100 |
2 × (75 – 90) |
| 2PGY1200×1000 |
φ1200 × 1000 |
≤ 80 |
100 – 120 |
2 × (75 – 132) |
| 2PGY1500×1200 |
φ1500 × 1200 |
≤ 120 |
150 – 200 |
2 × (132 – 160) |
| 2PGY1800×1000 |
φ1800 × 1000 |
≤ 100 |
250 – 300 |
2 × (250 – 315) |
| 2PGY2000×1200 |
φ2000 × 1200 |
≤ 120 |
300 – 400 |
2 × (315 – 355) |
Note: APEX roller skins can be fully customized (smooth, toothed, or specialized surfacing) to match your precise hardness and yield demands.
Optimize Your Ore Processing Circuit Today
Boost your ball mill efficiency or cement aggregate output with APEX heavy industrial intelligence. Reach out to our engineers for an immediate technical quote.
