River pebble, calcite, quartzite, marble, pebble, bentonite, iron ore, bluestone, mountain stone, water slag, limestone, weathered sand, diabase, granite, basalt and so on

Feed size:25-100mm
Productive capacity:5-450t/h

Application:Highway, railway, high-rise buildings, municipal, hydropower dam construction, concrete mixing station, sand and stone field, etc.

Get Quote

High-Abrasion Aggregate Blueprint

High-Efficiency Granite Crushing & Sand Production Solution

A streamlined, low-wear engineering blueprint deploying hydraulic double roller technology to conquer tough granite aggregates with minimum maintenance costs.

The Challenge: High Wear & Poor Particle Shape

Granite features a high quartz content, giving it a severe Mohs hardness of 6–7. When quarry operators use traditional impact crushers or VSIs (Vertical Shaft Impactors) for fine sand making, the highly abrasive granite tears through blow bars and liners within days. Furthermore, traditional compression setups often produce elongated, flaky needle-like particles that fail strict concrete grade specifications.

Granite

The Solution: Closed-Circuit Hydraulic Roll Fragmentation

Our streamlined solution optimizes the secondary and tertiary stages by replacing high-speed kinetic impactors with the 2PGY Hydraulic Double Roller Crusher. The system operates under a direct, closed-circuit configuration:

Rock-on-Rock Low Wear Mechanism

By utilizing low-RPM rotation combined with massive hydraulic cylinder pressure, the material is crushed through inter-particle compression. This minimizes direct sliding friction against the roller shells, extending liner lifespans by up to 4–6 times compared to impact systems.

Perfect Cubical Sand Matrix

The continuous, high-pressure planar squeeze shatters flat and elongated rocks easily. The final output yields highly consistent, cubical premium aggregate with a stable fineness modulus, ideal for high-strength ready-mix concrete.

Measurable Plant Gains

• Up to 60% Maintenance Cost Reduction: Eliminates weekly emergency shutdowns to swap out shattered impact bars.

• Optimized Fines Control: Minimizes useless stone dust waste, keeping valuable sand fractions within the high-revenue 0.15–5mm range.

• Automatic Tramp Protection: Dual hydraulic accumulators instant-bypass uncrushable excavator teeth or iron contaminants safely without stopping the line.
