Gold Mining Plant

Professional Alluvial & Placer Gold Recovery Solution

Overview

Gold Mining Plant mobile trommel screen is designed for alluvial placer gold ore processing, it’s consist of trommel screen, one diesel engine or electric motor, water pump& water pipes, and other facilities such as the grizzly feeding hoper and the mobile system. This mobile trommel machine normally works together with sluice box , gold centrifugal concentrator and shaking table to form a complete ore concentration plant. It has been widely used for alluvial gold, placer gold, tantalite, niobite, and tin ore concentration. It is very popular in Africa, Asia, South America due to its easy to move and easy operation, low cost.

Highlights

High Recovery Rate

Achieves a recovery rate of 75-80%, ensuring maximum gold recovery.

Customizable Capacity

Capacity can be customized from 10tph to 200tph, meeting various operational needs.

Robust Processing

Utilizes trommel screen, jig machine, sluice box, and shaking table for efficient separation.

Low Operating Costs

Economical operation with low power consumption, ideal for cost-conscious users.

工作流程介绍

Alluvial Gold Mining Processing Equipment Gold Trommel Screen Washing Machine Mobile Gold Recovery Separating Plant Operation Flowchart description:

Feed raw ore into grizzly feeding hopper with a excavator, large stones are prevented from entering by grizzly, and small pieces of material and sand enter into gold washing trommel screen.
Through the operation of gold trommel screen and the flushing of high-pressure water, large materials are discharged from the tail of trommel and sent to a remote place by the belt conveyor for stacking.
Small materials fine gold ores are discharged under the bottom of gold washing trommel and transported to the centrifuge concentrator for processing through steel chute or steel pipes.
The tailings from the centrifuge concentrator flow to the sluice box, and the grass mat in the sluice box captures and collects the useful ore.
The gold concentrates from the centrifuge concentrator will be separated again by shaking table. It is that removes impurities to get more pure gold concentrates.

Technical parameter

Model	Trommel Dimension (mm)	Productivity (t/h)	Motor Power (kw)	Dimensions (mm)	Weight (kg)
GTS0519	500 × 1900	5-10	1.5	3000 × 1000 × 1800	550
GTS1020	1000 × 2000	10-30	4.0	3390 × 1400 × 2140	1500
GTS1225	1200 × 2500	30-50	5.5	4146 × 1600 × 2680	2200
GTS1548	1500 × 4800	80-150	11.0	8460 × 2300 × 2500	6800
GTS1848	2000 × 4800	150-200	15.0	9860 × 2300 × 3420	7200
